五位移相器 技术指标
|
频率 (GHz) |
插损 (dBmax) |
驻波 (max) |
寄生调幅 (dB) |
相位精度 （°） |
承受功率 (W) |
|
0.5-1.0 |
1.8 |
1.3 |
±0.2 |
±2 |
2 |
|
1-2 |
2.2 |
1.4 |
±0.2 |
±2 |
2 |
|
2-4 |
3.0 |
1.5 |
±0.3 |
±3 |
2 |
|
4-8 |
4.5 |
1.6 |
±0.4 |
±3 |
2 |
|
8-12 |
5.5 |
1.8 |
±0.5 |
±3 |
2 |
|
12-18 |
8 |
2.0 |
±0.6 |
±5 |
2 |
|
18-26.5 |
9 |
2.0 |
±0.6 |
±5 |
0.2 |
|
24-30 |
9 |
2.0 |
±0.6 |
±5 |
0.2 |
|
27-34 |
9.5 |
2.0 |
±0.6 |
±5 |
0.2 |
|
32-36 |
9.5 |
2.0 |
±0.6 |
±5 |
0.2 |
六位移相器技术指标
|
频率 (GHz) |
插损 (dBmax) |
驻波 (max) |
寄生调幅 (dB) |
相位精度 （°） |
承受功率 (W) |
|
0.5-1.0 |
2.0 |
1.3 |
±0.2 |
±2 |
2 |
|
1-2 |
2.4 |
1.4 |
±0.3 |
±2 |
2 |
|
2-4 |
3.2 |
1.5 |
±0.3 |
±3 |
2 |
|
4-8 |
5.0 |
1.6 |
±0.4 |
±3 |
2 |
|
8-12 |
7.0 |
1.8 |
±0.5 |
±4 |
2 |
|
12-18 |
9 |
2.0 |
±0.8 |
±5 |
2 |
|
18-26.5 |
10 |
2.0 |
±0.8 |
±5 |
0.2 |
|
24-30 |
10 |
2.0 |
±0.8 |
±5 |
0.2 |
|
27-34 |
11 |
2.0 |
±0.8 |
±5 |
0.2 |
|
32-36 |
11 |
2.0 |
±0.8 |
±5 |
0.2 |
八位移相器 技术指标
|
频率 (GHz) |
插损 (dBmax) |
驻波 (max) |
寄生调幅 (dB) |
相位精度 （°） |
承受功率 (W) |
|
0.5-1.0 |
2.6 |
1.3 |
±0.2 |
±2 |
2 |
|
1-2 |
3.2 |
1.4 |
±0.3 |
±2 |
2 |
|
2-4 |
4.2 |
1.5 |
±0.3 |
±3 |
2 |
|
4-8 |
6.6 |
1.6 |
±0.4 |
±3 |
2 |
|
8-12 |
9.2 |
1.8 |
±0.5 |
±4 |
2 |
|
12-18 |
12 |
2.0 |
±0.8 |
±5 |
2 |
|
18-26.5 |
12 |
2.0 |
±0.8 |
±5 |
0.2 |
|
24-30 |
13 |
2.0 |
±0.8 |
±5 |
0.2 |
|
27-34 |
13 |
2.0 |
±0.8 |
±5 |
0.2 |
|
32-36 |
14 |
2.0 |
±0.8 |
±5 |
0.2 |
